Available Painted Trail MTB Frame P1

  • 29er full suspension frame
  • Boost 148mm rear spacing
  • 200x51mm rear shock
  • 130-140mm travel suspension fork
  • BSA bottom bracket
₩1,189,000
₩1,189,000
₩1,189,000
Size: Size M & Glossy Blue
Subtotal: ₩1,189,000
10 customers are viewing this product

Fast Delivery

15-Year Quality Assurance

2-year Warranty

Available Painted Trail MTB Frame P1

Available Painted Trail MTB Frame P1

₩1,189,000

Available Painted Trail MTB Frame P1

₩1,189,000
Size: Size M & Glossy Blue

Specification

Type Full Carbon Suspension MTB frame
Model P1
Wheel Size 27.5er/29er
Material 100% carbon fiber Toray T700
Weave UD Matt
Frame Travel 130mm
Brake Front 180mm, Rear 160mm
Rear Shock 200*51mm
 Frame Weight 2410g (M, UDM), 2445g(S, Pink)
Frame Size XS/S/M/L/XL
Bottom Bracket BSA
Headset Top 1-1/8",down 1- 1/2"
Seatpost 31.6mm

Seatpost Clamp

34.9mm
Axle 148*12mm
Tire

27.5 *2.8'' or 29* 2.35''

If XDR groupset , 27.5*2.5" or 29*2.3'



Rear Shock Eye to Eye: 200*51mm or 200*57mm

Rear Shock Hardware: 22.2mmx8mm

Front Fork Travel: 130-140mm for 29er wheels (140-150mm for 27.5 plus wheels)

Disc Rotor size:160mm

Supported Rear Shock

  • FOX Float DPS Factory
  • Rockshox Monarch  200*51mm

Ready to build up your own light and durable carbon Trail/AM MTB frame? Or upgrade your current frame? No better place to start than with a quality and affordable carbon frame. This P1 frame from ICAN Cycling is a light in durable options for those looking for a full suspension with 130mm rear travel. Built with triple enforced T800 Carbon, a 31.6 seat tube for wider posts and dropper posts, and equipped with a durable, stiff, and low maintenance and durable BSA English Threaded bottom bracket, this frame is for those looking to be efficient, yet bomb decents with some big jumps thrown in.

This frame is designed in the style of Trek Fuel, and can take 29er or 27.5+ wheels. The frame can take up 130-140mm fork in the front with 29er wheels and 140-150mm fork with 27.5+ wheels.

Can I use a 68mm bsa bottom bracket for a size large P1 frame?

Yes.

The whole mountain bike world has gone boost crazy. This has probably made you feel like you want a boost frame. The only thing to hold you back has cost, well now we have built you the solution to your problem. Behold our carbon fibre full suspension boost mountain bike frame.

To keep prices down, we have concentrated on our R&D and not our marketing department or fancy name professionals. Nope, we are only interested in creating the best carbon fibre cycling products for you. Our boost frameset perfectly fits that mentality by being entirely up to date, very high quality and high tech but it does not feature a high price tag.

Instead of building with dollar or pound signs it comes bulging with features. The frame is constructed from Toray T700 carbon fibre. Allowing our engineers to create a lightweight and stiff frame. They have achieved extra stiffness by using a 148mm by 12mm rear end. Making it possible for the frame to become wider; this helps to stiffen up pivot joints and make them longer lasting.

With 130mm of travel and a BSA bottom bracket, you can be sure that this frame will be capable of taking you anywhere with a nice amount of travel and a reliable bottom bracket system. To add to the reliability, we have used our famous internal routing system for making sure your cables and hoses can be fitted quickly and easily.

P1 geometry



Warranty Policy

Every ICAN frame and rim has a useful product life cycle. Each bike, frame and rim will have a unique identification number and warranty card. Complete the provided card and warranty form, and send them to us. Failure to use the provided warranty card will void your warranty. Save your dated receipt for proof of purchase.

Product Group:

Frame and Rim

Applies to all ICAN and Triaero brand bike frame, and FL Max series, AERO Series, and Alpha series rim.

Coverage:

2-year warranty from the date of purchase.

Conditions:

  1. If any manufacturing defect occurs within 30 days of the date of purchase, is obligated to replace the rim(s) and also pay for the shipping cost. If any manufacturing defect occurs after 31 days and up to 2 years, ICAN is obligated to replace the product(s). The product owner is responsible for shipping costs.
  2. If we no longer make the rim you purchased we’ll upgrade you to the newest equivalent model at no extra cost.
  3. The Warranty program is not transferable and only applies to the initial purchaser.

This warranty does not cover:

  • Normal wear and tear (bearings, spokes, nipples, brake tracks, tires, inner tubes, pawls, freehub, seals, rim tape etc.)
  • Products which have been incorrectly installed and/or adjusted.
  • Issues brought about by neglect or poor maintenance.
  • Surface finish and cosmetic treatments (anodizing, decals, etc.)
  • Crash damage.
  • Consequential or incidental damages (where applicable)
  • Products purchased “second-hand”, “used”, “as-is”, or expressly “without warranty”
  • Counterfeit products
  • Unauthorized modification or alteration, including without limitation, any repair performed by anyone other than ICAN or an ICAN-authorized servicer, or outside of the recommendations of ICAN Customer Service

Tips:Please contact the official support of ICAN at the first time when you find a quality problem. Please do not repair our products privately, otherwise we will not bear any warranty.

The following will void your warranty

  • Misuse (Jumping, trick riding, etc.)
  • Modification of wheels
  • Tire pressure exceeding 140psi
  • Improper assembly
  • Installation of parts or accessories not originally intended for, or not compatible with the wheelsets sold.
  • Use of brake pads not designed for carbon wheels

More details can be known from "Warranty & Return".
